Overview：

Bently Nevada 3500/45E Position Monitor

Bently Nevada 3500/45E is a 4-channel position monitor. This monitor can receive input signals from proximity sensors, rotary position transducers (RPTs), AC/DC linear variable differential transformers (AC/DC LVDTs, where AC LVDTs are only supported by the Encore 1.0 version of the 3300 rack upgrade), and rotary potentiometers. The 3500/45E processes these input signals to measure various position-type parameters and compare them with user-programmable alarm thresholds.

Contact now

Specification：

Parameter	Details
Model Number	3500/45E
Rotary Potentiometer Valve Position	41 mV/degree rotation.
Front Panel LEDs - OK LED	Indicates when the 3500/45E is operating properly.
Front Panel LEDs - DANGER LED	Indicates the 3500/45E has detected a danger condition and is driving the danger relay.
AC LVDT	2.3 V rms 3400 Hz sine wave.
Rotary Potentiometer	-14.68 Vdc.
Dimensions (Height × Width × Depth)	228mm* 50mm *289mm
Weight	1.27kg

Function & Features：

Signal Conditioning and Measurement:The 3500/45E processes the input signals and outputs position-type parameters such as axial position and differential expansion, and can also generate "static values" for alarm determination.

Tiered Alarm Settings:The 3500/45E can configure Alert thresholds for each activated "static value," and can also set Danger thresholds for any two static values.

Efficiency Analysis:The 3500/45E correlates valve position data with other process parameters (such as steam temperature and pressure) to analyze and evaluate the overall operating efficiency of the turbine.
