Bently Nevada 3500/22M 138607-01 Transient Data Interface Module
Overview
The 3500/22M 138607-01 Transient Data Interface Module (TDI) is a communications and data acquisition module in the Bently Nevada 3500 Series Machinery Monitoring System. It combines the functionality of the 3500/20 Rack Interface Module (RIM) with the data collection capabilities of a communications processor (such as TDXnet), sits in the slot next to the 3500 rack power supply, and interacts with the M Series Monitors (3500/40M, 3500/42M, etc.) to collect transient dynamic (waveform) data and transmit the data to the host software over an Ethernet link.
Function & Features
3500/22M 138607-01
Supports multiple data types
- Steady-state data (standard feature) to continuously monitor equipment health.
- Transient dynamic (waveform) data (requires optional channel-enabled disk).
- High-resolution transient capture (for vibration, speed, and process signal analysis).
Ethernet Communications-Data is transmitted to
- System1™ Condition Monitoring Software (for predictive maintenance).
- 3500 Configuration Software (for system setup and diagnostics).
- Supports M-Series monitors (e.g., 3500/40M, 3500/42M)
Specifications
|
Parameter |
Details |
| Series | 3500/22M |
| Model number | 138607-01 |
|
Power Consumption |
10.5 Watts |
|
Front Panel |
USB - B |
|
10Base - T/100Base - TX I/O |
10Base - T or 100Base - TX Ethernet, autosensing |
|
100Base - FX I/O |
100Base - FX Fiber - Optic Ethernet |
|
Trip Multiply - Description |
Used to place 3500 rack in Trip Multiply |
|
Trip Multiply - Maximum Current |
<1 mAdc, Dry Contact to Common |
|
Operating Temperature |
-30°C to 65°C (-22°F to +149°F) |
|
Dimensions (Height x Width x Depth) |
241.3 mm x 24.4 mm x 241.8 mm (9.50 in x 0.96 in x 9.52 in) |
|
Weight |
0.91 kg (2.0 lbs) |
Questions & Answers
FAQ
Q: What is the brand?
A: Bently Nevada
Q: What is the type?
A: Transient Data Interface Module
Q: What is the warranty?
A: 1 year
Q: Where is the shipping location?
A: Xiamen
Q: What is the payment method?
A: T/T
Q: Why choose us?
A: We are the supplier for industrial automation spare parts,We speciaized in PLC DCS and TSl system modules and spare parts for 10 years, With our professional expertise and extensive experience, we are well-equipped to meet your requirements.
