Overview：
The IOCN 200-566-000-114 is a modular CPU card and input/output card. The module is a component of a rack-mounted Machinery Protection System (MPS) and/or Condition Monitoring System (CMS). The card is paired with the CPUM card to form a complete rack controller and communication interface unit.
The IOCN exists as a card pair consisting of a rack controller and a communication interface card, and primarily performs signal transmission and communication interface expansion functions for the CPUM card.
Specifications：
| Parameter | Details |
|---|---|
| Part Number (PNR) | 200-566-000-114 |
| Role | Input/Output & Communication Interface Card (must be paired with a CPUM card) |
| Belongs to System | Rack-based Machinery Protection System (MPS) / Condition Monitoring System (CMS) |
| Paired CPU Card | Must be paired with a CPUM card (PNR: 200-595-xxx-xxx). Non-functional alone. |
| Data Transfer Rate | Up to 10 Mbps |
| Distance Between Devices | Up to 100 m |
| Protocols | Modbus TCP |
Function & Features：
- Core carrier for system control and communication gateway:The IOCN 200-566-000-114 card, paired with the CPUM card, forms a card pair that serves as the rack controller and communication interface core component of the MPS system and CMS system, providing both system control and data communication gateway functions.
- Dedicated signal and communication interfaces for the CPUM card:The IOCN 200-566-000-114 card is specifically responsible for signal transmission and communication interface expansion for the CPUM card. When used in combination with the CPUM card, the IOCN routes the primary/backup Ethernet connections and secondary serial connections of the CPUM card to the front-panel interfaces of the IOCN.
- Networking and data interaction support:The IOCN 200-566-000-114 card supports the construction of multi-node rack networks. Through two pairs of serial interfaces (A/B), the card connects to optional serial communication modules and assists the CPUM card in completing data interaction with monitoring cards such as MPC4 and AMC8.
Questions & Answers
💡 FAQ
Q: How is the IOCN 200-566-000-114 card installed?
A: The IOCN is a single-width card and must be installed in the corresponding slot at the rear of the rack.
Q: What are the differences between CPUM/IOCN and CPUR/IOCR or CPUR2/IOCR2?
A: CPUM/IOCN:
Base version with a front-panel display, supporting Modbus and PROFINET.
CPUR/IOCR:
Adds rack controller hardware redundancy.
CPUR2/IOCR2:
Builds on the redundant architecture and further adds fieldbus data mathematical processing capabilities, with support for PROFIBUS DP.
Q: What is the warranty?
A: 1 year
Q: What is the return and exchange policy?
A: Returns or exchanges are accepted within 7 days of receiving the goods if there are any quality issues, excluding damage caused by human error or misuse.
Q:What are the available shipping methods?
A: FedEx, DHL, UPS, and others.
