Description

GE IS200TDBTH6A Discrete I/O Terminal Board

Overview

GE IS200TDBTH6A is a discrete I/O terminal board for the Mark VIe distributed control system. It is a triple modular redundant (TMR) discrete input/output terminal board that ensures 99.99% availability through 3 independent PDIO channels, has a built-in contact resistance monitoring circuit, no motherboard jumpers, and is plug-and-play. The mechanical life of the relay of IS200TDBTH6A is >100,000 times.

🚀Function & Features

The IS200TDBTH6A works with the PDIO I/O module group to form a specific connection architecture.

The IS200TDBTH6A has 12 Form-C relay outputs and can be connected to option cards for expansion functions.

The onboard signal conditioning and contact input functions can handle a variety of voltages, the input current is limited according to different circuits, and the power supply is limited by fuses.

The IS200TDBTH6A itself has no hardware configuration/jumpers, and the option board jumpers are assembled or removed as needed.

Specifications

Parameter	Specification
Model Number	IS200TDBTH6A
Series	Mark VIe
Input Channels	24 group-isolated contact inputs
Wetting Voltage Support	24/48/125V DC (external supply)
Input Voltage Ranges	16-32V DC / 32-64V DC / 100-145V DC
Current Limitation	• 2.5mA (Channels 1-21) • 10mA (Channels 22-24) • 0.5A max for 24V DC (PTC resettable fuse)
