overview：
Woodward 5464-648 is an analog 8-channel output module (4-20mA) for gas turbine control systems. It is often connected to a PLC or DCS to control external devices or systems by generating analog voltage or current signals. It has eight independent analog output channels, each of which can control up to eight devices or processes simultaneously, improving the efficiency of large-scale operations; it provides a current output (4-20mA) signal type suitable for industrial applications that require a standard current loop; it is easy to configure to meet the specific needs of different applications, and parameters such as output range and scale factor can be programmed using software tools provided by the manufacturer.
Fuctions & Features:
- Number of Channels: The Woodward 5464-648 module features eight independent analog output channels, each capable of controlling up to eight devices or processes simultaneously, improving the efficiency of large-scale operations.
- Signal Type and Range: The Woodward 5464-648 module provides current output (4-20mA) for industrial applications requiring a standard current loop.
- Configuration and Programming: The Woodward 5464-648 module is easily configurable to meet the specific needs of each application. Parameters such as output range and scaling factor can be programmed using a manufacturer-provided software tool.
Specification:
|
Specification |
Details |
|
Number of Channels |
2 |
|
Actuator Type |
Proportional or integrating, hydromechanical or pneumatic actuators |
|
Power requirements |
+5 V @ 0.5 A, +24 V @ 1 A |
|
Manual |
26166V2 MicroNet Simplex & MicroNet Plus |
|
Driver - Current range |
10 mA Version: ±12.25 mA max |
|
Driver - Dither Current |
25 Hz, 25% duty cycle, tunable amplitude |
|
Driver - Max Load Resistance |
10/(maximum current required, in amps) |
