Overview：
GE IS230PCAAH1A Core Analog I/O Module
GE IS230PCAAH1A is a core analog I/O module that works with supporting termination boards (such as TCAS and TCAT) to process various analog signals and output control commands. Internally, the module consists of a processor board shared with all I/O boards, two application I/O boards, and a termination board. The entire module is considered a minimum replaceable unit (MRU), requiring replacement of the entire module.
Related products: IS230PCAAH1B
Function & Features：
- Signal Grouping: The IS230PCAAH1A signals are divided into two categories: one category can be fanned out to multiple redundant modules via a TCAT termination board; the other category connects directly to the module's terminals and is dedicated to a single module.
- Optional Termination Board: If signal fanout is not required, the IS230PCAAH1A module can be used standalone without a TCAT termination board.
- Signal Distribution: A single TCAT termination board can distribute signals to one, two, or three IS230PCAAH1A modules.
Specifications：
| Parameter | Description |
|---|---|
| Product Model | IS230PCAAH1A |
| Power Connectors | P4 connector (from JGPA board), P5 connector |
| I/O Connection | 120 Euro-style terminals |
| Vibration Monitoring | Seismic sensor input |
| Terminal Board Interfaces | 2 x 68-pin connectors |
| Terminal Board Models | TCAT or TCAS |
