overview：
ABB 88QT03C-E GJR2374500R2111 bus coupling module consists of three main functional blocks: the specific station bus function part processor I, which is mainly responsible for handling the overall data communication with the station bus using the SS standard interface.
The processing part processor II mainly includes the function of marshaling the PROCONTROL-PS bus telegrams from the PROCONTROL-PS bus shared memory into telegram or bit form for transmission to the station bus send shared memory.
The specific PROCONTROL-PS bus function part is mainly responsible for handling the data communication with the PROCONTROL-PS bus using the SEA standard interface.
Fuctions & Features:
Core Advantages
Module installation and addressing:
- Occupies 2 standard slots and is installed in the PROCONTROL bus system processing station.
- Must be inserted at an even address (such as 0, 2, 4...).
- Adjacent odd addresses are automatically reserved, but cannot be assigned to other modules.
Interface and connection:
- Communicate with the system master through the SS standard interface.
- Connect the protection system module (such as analog/digital I/O) through the SEA standard interface.
- Provide terminals for direct access to external signals.
| Type | Model Example | Function Description |
| Analog Input | 70EA01-ES/R1 | One data message per functional unit |
| Binary Input | 70EB02-ES/R4 | One data message per module |
| Binary Output | 70AB01-ES/R2 | One data message per module |
| Calculation Module | 70PR03-ES/R2 | Logical operation and data processing |
| RS485 Bus Coupler | 70BK03-ES/R2 | Expand PROCONTROL-PS bus communication |
Specification：
| Parameter Category | Parameter Name | Value |
| Power supply | Operating voltage | US = 24 V |
| Current consumption | IS = 0.5 A | |
| Power dissipation, typ. | P = 12 W | |
| Reference potential | Z = 0 V | |
| Module interfaces | Interface with station bus | SS – Standard interface |
| Interface with PROCONTROL–PS bus | SEA – Standard interface |
