ABB 560PSU01 RTU560 Power Supply Unit
Overview
The ABB 560PSU01 RTU560 Power Supply Unit is a dedicated plug-in power module specifically designed for the ABB RTU560 Remote Terminal Unit (RTU) rack system. Tailored for substation automation and power grid monitoring applications, this module converts an industrial input voltage of 110–220 V DC into regulated 5 V DC and 24 V DC outputs, thereby providing power support for the control boards, communication modules, and field acquisition units within the RTU560 system.
The ABB 560PSU01 RTU560 Power Supply Unit integrates comprehensive circuit protection features and employs passive cooling via natural convection. It supports parallel redundant operation and automatic load balancing capabilities, making it fully suited for the long-term, unattended operational environments typically encountered in the power industry.
Function&Features：
ABB 560PSU01 RTU560
- Dedicated RTU560 Power Output: Provides standard dual-channel outputs of 5V DC and 24V DC, meeting the power supply requirements of all internal modules within the RTU560 Remote Terminal Unit during full-load operation.
- Multiple Circuit Protections: Equipped with input overvoltage protection, reverse polarity protection, output short-circuit protection, and electronic current limiting capabilities to effectively prevent module damage caused by field voltage fluctuations or circuit faults.
- Isolated Power Design: Features 1500 VAC dielectric isolation between the input and output terminals, effectively reducing signal interference and enhancing equipment operational stability in complex electromagnetic environments.
- Power Redundancy Support: Supports the parallel operation of multiple 560PSU01 modules, enabling automatic load balancing and fault-over functions for power redundancy systems.
- Passive Cooling Design:Employs a natural convection cooling structure that requires no fan assistance, thereby lowering the equipment failure rate and reducing the frequency of routine maintenance.
- Real-time Status Monitoring: Built-in LED indicators provide real-time status displays of the output voltage, facilitating easy status inspections and troubleshooting by field personnel.
- Rapid Integration and Installation: Utilizes a standard backplane plug-in structure compatible with RTU560 racks, eliminating the need for additional wiring modifications during equipment replacement or system upgrades.
Specifications：
|
Parameter |
Value |
|
Product Model |
560PSU01 |
|
Product Name |
ABB 560PSU01 RTU560 Power Supply Unit |
|
Part Number |
1KGT006600R0002 |
|
Applicable System |
ABB RTU560 Remote Terminal Unit Rack System |
|
Input Voltage Range |
110 V DC ~ 220 V DC |
|
Output Voltage |
5 V DC, 24 V DC |
|
Dielectric Isolation |
1500 VAC |
|
Temperature Range |
-25°C to +70°C |
|
Relative Humidity |
5% to 95% (Non-condensing) |
|
Height |
132.8mm |
|
Width |
482.6mm |
| Length | 210mm |
|
Weight |
0.5KG |
ABB SD823 - Q&a
Q: What are the primary application areas for the ABB 560PSU01 power supply unit?
A: The 560PSU01 is a dedicated power supply module specifically designed for the ABB RTU560 Remote Terminal Unit (RTU), providing a stable DC power source for substation automation and power grid monitoring systems.
Q: Which RTU systems does the 560PSU01 support?
A: It fully supports the complete ABB RTU560 rack system and is compatible with all standard RTU560 function modules and backplane slots.
Q: What are the input and output voltage specifications for the 560PSU01?
A: The module accepts an input voltage range of 110 VDC to 220 VDC and provides dual regulated outputs of 5 VDC and 24 VDC to power the internal circuit boards of the RTU.
Q: Does this module support isolation protection features?
A: It features a dielectric isolation capability of 1500 VAC between the input and output terminals, which helps to mitigate electromagnetic interference within substation environments.
Q: What protection functions are built into the 560PSU01?
A: The module incorporates overvoltage protection, reverse polarity protection, output short-circuit protection, and electronic current limiting protection.
Q: Can the 560PSU01 directly replace older RTU560 power supply modules?
A: It is fully compatible with standard RTU560 racks and supports "plug-and-play" functionality, allowing for direct replacement without the need for system modifications or rewiring.
Q: What is the brand?
A: ABB
Q: What is the type?
A: Power Supply Unit
Q: What is the warranty?
A: 1 year
Q: Where is the shipping lovation?
A: Xiamen
Q: What is the payment method?
A: T/T
Q: Why choose us?
A: We are the supplier for industrial automation spare parts,We speciaized in PLC DCS and TSl system modules and spare parts for 10 years, With our professional expertise and extensive experience, we are well-equipped to meet your requirements.
